I
-
See Also
System Measurements Menu Map and Softkey Descriptions
System Measurements
Softkey
Function Descriptions
Table 6-2. Information Contained in a Printout
Number
Description
1
Date and time the measurements were begun,* (Time is given in a
24-hour
format.1
2 The location code.”
3 The temperature.*
4 The analyzer serial
number.?
5 Whether or not the spectrum analyzer had an oven reference.+ The oven reference is available as ar
option (Option 0041 for HP 8590 E-Series spectrum analyzers and is standard on the HP
85911:
analyzer.
6 The tune configuration.
7 The results of the composite triple beat testing
lif
CTB testing was selected when the testing was
performed).
8 The file number of test data file.
9 The tests.
10
The test results. An entry with a dash (‘-‘I indicates that the test was not performed.
11 The channel number.
12
The asterisk indicates that the channel was selected as a scrambled channel.
The location code and temperature entry are entered by the operator.
The information for this entry is from the analyzer used to do the testing.
Press CABLE TV ANALYZER, SYSTEM
MEAS,
More 1 of 2 , Recall Data
to access DATA TO PRINTER
“Step 3. Install a printer” in Chapter 1.
6-12
