I
-
Cable
TV
Measurement
Specifications
and
Characteristics
S@ecijications
describe the warranted performance of the HP 85721A cable
TV measurements and system monitor personality with supported analyzer
over the temperature range of 0
“C
to 55
OC,.
The analyzer will meet its
speciEcations after 2 hours of storage at a constant temperature within the
operating temperature range, 30 minutes after the analyzer is turned on, and
after CAL FREQ, CAL AMPTD have been run.
Churucteristics
provide useful, but non-warranted, information in the form of
typical, nominal, or approximate values for analyzer performance.
Input Configuration
Select input conditions of spectrum analyzer.
75
fI
Spectrum Analyzer
50
f2
Spectrum Analyzer
50
fI
Spectrum Analyzer Selections:
HP 8590 Series Option 711 Ext Pad
No Ext Pad
No selection required
Measurements converted to 75
n
values
Amplitude offset set to 5.8
dB
Amplitude offset set to zero
Channel Selection
Tune Configuration
Channel Range
Channel Frequencies
Frequency Range
Amplitude Range
Analyzer tunes to specified channels based upon selected tune
configuration.
Standard, Off-the Air, HRC, IRC
IT
and FM channels also in channel
model
1 to 158 and
201
to 300 [channel mode)
1 to 158 [system model
2 to 134
fOplion
1071
Defined by Code of Federal Regulations,
Title 47, Telecommunications,
Parts 73.603, 76.605, 76.612
5 to 1002 MHz [channel model
54 to 896 MHz [system model
50 to 850 MHz [Option
1071
-15 to
+70
dBmV
for S/N
>
30
dB
Visual-Carrier Frequency
Visual-carrier frequency is counted
9-3
