Installation and Getting Started Guide
7 - 40
NOTE: If many of your VLANs will have an identical configuration, you might want to configure VLAN groups and
virtual interface groups after you increase the system capacity for VLANs and virtual interfaces. See “Configuring
VLAN Groups and Virtual Interface Groups” on page 7-37.
Increasing the Number of VLANs You Can Configure
To increase the size of the VLAN table, which determines how many VLANs you can configure, use either of the
following methods.
NOTE: Although you can specify up to 4095 VLANs, you can configure only 4094 VLANs. VLAN ID 4094 is
reserved for use by the Single Spanning Tree feature.
USING THE CLI
To increase the maximum number of VLANs you can configure, enter commands such as the following at the
global CONFIG level of the CLI:
HP9300(config)# system-max vlan 2048
HP9300(config)# write memory
HP9300(config)# end
HP9300# reload
Syntax:
system-max vlan <num>
The <num> parameter indicates the maximum number of VLANs. The range of valid values depends on the
device you are configuring. See Table 7.1.
USING THE WEB MANAGEMENT INTERFACE
To modify a table size using the Web management interface:
1. Log on to the device using a valid user name and password for read-write access. The System configuration
panel is displayed.
2. Select the Max-Parameter
link to display the Configure System Parameter Maximum Value table. This table
lists the settings and valid ranges for all the configurable table sizes on the device.
3. Click the Modify button next to the row for the parameter (in this case, “vlan”).
4. Enter the new value for the table size. The value you enter specifies the maximum number of entries the table
can hold.
Table 7.1: VLAN and Virtual Interface Support
Product VLANs Virtual Interfaces
Default
Maximum
Configurable
Maximum
Default
Maximum
Configurable
Maximum
HP 9304M, HP 9308M, or HP 9315M
Routing Switch
with 256MB Redundant Management
module (M4)
32 4095 255 4095
HP 9304M, HP 9308M, or HP 9315M
Routing Switch
with 128MB Redundant Management
module (M2)
16 512 255 512
