9. Specify the port that are members for the VLAN:
• Select Dynamic Port if you want the port membership to be dynamic. For information, see “Dynamic
Ports” on page 7-9.
• Click the Change Static Members button if you want to configure static ports. For information, see “Static
Ports” on page 7-10.
• Click the Change Exclude Members button if you want to explicitly exclude some ports. For information,
see “Excluded Ports” on page 7-10.
NOTE: All the ports must be members of the port-based VLAN that contains this AppleTalk cable VLAN.
See “Layer 3 Protocol-Based VLANs” on page 7-3.
10. Click the Add button (if you are adding a new VLAN) or the Modify button (if you are modifying an existing
VLAN) to save the change to the device’s running-config file.
11. Select the Save
link at the bottom of the dialog. Select Yes when prompted to save the configuration change
to the startup-config file on the device’s flash memory.
Displaying VLAN Information
After you configure the VLANs, you can verify the configuration using the following methods.
NOTE: If a VLAN name begins with “GVRP_VLAN_“, the VLAN was created by the GARP VLAN Registration
Protocol (GVRP). If a VLAN name begins with “STATIC_VLAN_“, the VLAN was created by GVRP and then was
converted into a statically configured VLAN.
Displaying System-Wide VLAN Information
Use one of the following methods to display VLAN information for all the VLANs configured on the device.
