Installation and Getting Started Guide
3 - 8
• Slots in a 15-slot chassis are numbered 1 – 15, from left to right.
USING THE CLI
To display the status of a redundant management module using the CLI, enter the following command at any CLI
level:
Syntax:
show module
NOTE: The module descriptions do not distinguish between SX and LX ports.
The Status column shows the module status. The redundant management modules can have one of the following
statuses:
• ACTIVE – The module is currently the active management module.
• STANDBY – The module is the standby management module.
• COMING UP – The module is coming up as the standby module. This status can be observed during
switchover.
The statuses above apply only to management modules. The following statuses apply only to host modules:
• FAILED – This status applies only to host modules, not to management modules. This status indicates that
the host module failed to come up.
• OK – This status applies only to host modules, not to management modules. This status indicates that the
module came up and is operating normally.
USING THE WEB MANAGEMENT INTERFACE
1. Log on to the device using a valid user name and password for read-write access. The System configuration
dialog is displayed.
2. Click on the Module
link to display the Module panel, as shown in the following example.
HP9300> show module
Module Status Ports Starting MAC
S1: 8 Port Gig Management Module ACTIVE 8 00e0.5202.a2d4
S2: 24 Port Copper Module OK 24 00e0.5202.a2d4
S3: 24 Port Copper Module OK 24 00e0.5202.a2d4
S4: 24 Port Copper Module OK 24 00e0.5202.a2d4
S5: 8 Port Gig Management Module STANDBY 8 00e0.5202.a334
S6: 24 Port Copper Module OK 24 00e0.5202.a2d4
S7: 24 Port Copper Module OK 24 00e0.5202.a2d4
S8: 24 Port Copper Module OK 24 00e0.5202.a2d4
