Page #101 background imageLoading...
Page #101 background image
Poor performance.
Cause Solution
Low on memory. Add more memory.
Hard drive fragmented. Defragment hard drive.
Program previously accessed did not release reserved memory
back to the system.
Restart the computer.
Virus resident on the hard drive. Run virus protection program.
Too many applications running. 1. Close unnecessary applications to free up memory.
2. Add more memory.
3. Some applications run in the background and can be closed
by right-clicking on their corresponding icons in the task
tray. To prevent these applications from launching at
startup:
In Windows 7:
a. Go to Start > All Programs > Accessories > Run
b. Type msconfig, and then press Enter.
c. On the Startup tab of the System Conguration Utility,
clear applications that you do not want to launch
automatically, and the click OK.
In Windows 10:
a. Type msconfig in the taskbar search box, and then
select mscong.
b. On the Startup tab of the System Conguration Utility,
click Open Task Manager.
c. Select applications that you do not want to launch
automatically, and the click Disable.
Some software applications, especially games, are stressful on
the graphics subsystem.
1. Lower the display resolution for the current application or
consult the documentation that came with the application
for suggestions on how to improve performance by
adjusting parameters in the application.
2. Add more memory.
3. Upgrade the graphics solution.
Cause unknown. Restart the computer.
Computer powered o automatically and the Power LED ashes red four times and then white two times.
Cause Solution
Processor thermal protection activated:
A fan may be blocked or not turning.
OR
The heat sink is not properly attached to the processor.
1. Ensure that the computer air vents are not blocked and the
processor cooling fan is running.
2. Open the access panel, press the power button, and see if
the processor fan (or other system fan) spins. If the fan does
not spin, make sure the fan cable is plugged onto the system
board header.
3. If fan a plugged in and not spinning, replace it.
Solving general problems 91

Table of Contents

Other manuals for HP EliteDesk 800 G3 TWR

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP EliteDesk 800 G3 TWR and is the answer not in the manual?

HP EliteDesk 800 G3 TWR Specifications

General IconGeneral
Form FactorTower
Processor OptionsIntel Pentium, Intel Celeron
MemoryUp to 64 GB DDR4-2400 SDRAM
Storage Options2.5" HDD/SSD, M.2 SSD
GraphicsIntel HD Graphics 630
Operating SystemWindows 10 Pro
AudioRealtek HD ALC221-VB Audio
Expansion Slots1 PCIe x16
Ports (Front)2 x USB 3.1 Gen 1, 2 x USB 2.0, 1 x headphone/microphone combo
Ports (Rear)4 x USB 3.1 Gen 1, 4 x USB 2.0, 1 x VGA, 1 x DisplayPort, 1 x RJ-45, 1 x audio line-out, 1 x audio line-in
Power Supply250W, up to 92% efficient PSU
Optical DriveOptional DVD-Writer
ChipsetIntel® Q270
