Hood lock (solenoid)
The hood lock is secured to the rear of the chassis with two screws.
1. Prepare the computer for disassembly (Preparation for disassembly on page 19).
2. Remove the access panel (Access panel on page 20).
3. From the rear of the chassis, remove the two security screws that secure the hood lock.
4. From the inside of the chassis, disconnect the cable from the system board connector labeled HLCK (1).
5. Remove the hood lock from the inside of the computer (2).
To install the hood lock, reverse the removal procedure.
62 Chapter 4 Removal and replacement procedures – Microtower (MT) chassis
