Front panel components
Drive conguration may vary by model. Some models have a bezel blank covering one or more drive bays.
Front panel components
1 5.25-inch half-height drive bay (behind bezel) 7 Audio-out (headphone) jack
2 Slim optical drive (optional) 8 USB 2.0 port with HP Sleep and Charge
3 SD card reader (optional) 9 USB 2.0 port
4 Power button 10 USB 3.x ports (2)
5 Hard drive activity light 11 USB Type-C charging port
6 Audio-out (headphone)/Audio-in (microphone) combo
jack
NOTE: The light on the power button is normally white when the power is on. If it is ashing red, there is a problem with
the computer and it is displaying a diagnostic code. Refer to the Maintenance and Service Guide to interpret the code.
2 Chapter 1 Product features

Table of Contents

Other manuals for HP EliteDesk 800 G3 TWR

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP EliteDesk 800 G3 TWR and is the answer not in the manual?

HP EliteDesk 800 G3 TWR Specifications

General IconGeneral
Form FactorTower
Processor OptionsIntel Pentium, Intel Celeron
MemoryUp to 64 GB DDR4-2400 SDRAM
Storage Options2.5" HDD/SSD, M.2 SSD
GraphicsIntel HD Graphics 630
Operating SystemWindows 10 Pro
AudioRealtek HD ALC221-VB Audio
Expansion Slots1 PCIe x16
Ports (Front)2 x USB 3.1 Gen 1, 2 x USB 2.0, 1 x headphone/microphone combo
Ports (Rear)4 x USB 3.1 Gen 1, 4 x USB 2.0, 1 x VGA, 1 x DisplayPort, 1 x RJ-45, 1 x audio line-out, 1 x audio line-in
Power Supply250W, up to 92% efficient PSU
Optical DriveOptional DVD-Writer
ChipsetIntel® Q270
