Rear panel components
Rear panel components
1 Audio-out jack for powered audio devices 6 Audio-in jack
2 DisplayPort monitor connectors (2) 7 RJ-45 (network) jack
3 Optional port (DisplayPort, HDMI, VGA or USB-C)
(USB-C option has alt mode DisplayPort or 15W
output)
8 Optional serial port
4 USB 2.0 ports with wake from S4/S5 (2) 9 Power cord connector
5 USB 3.x ports (4)
NOTE: Your model may have additional optional ports available from HP.
When a device is plugged into either audio jack, a dialog box will appear on the monitor screen asking if you want to use the
jack for a microphone or a headphone. You can also recongure the jacks at any time by double-clicking the Audio Manager
icon in the Windows taskbar.
When a graphics card is installed in one of the system board slots, the video connectors on the graphics card and/or the
integrated graphics on the system board may be used. The specic graphics card installed and software conguration will
determine the behavior.
The system board graphics can be disabled by changing settings in BIOS F10 Setup.
Rear panel components 3

HP EliteDesk 800 G3 TWR Specifications

General

Form Factor	Tower
Processor Options	Intel Pentium, Intel Celeron
Memory	Up to 64 GB DDR4-2400 SDRAM
Storage Options	2.5" HDD/SSD, M.2 SSD
Graphics	Intel HD Graphics 630
Operating System	Windows 10 Pro
Audio	Realtek HD ALC221-VB Audio
Expansion Slots	1 PCIe x16
Ports (Front)	2 x USB 3.1 Gen 1, 2 x USB 2.0, 1 x headphone/microphone combo
Ports (Rear)	4 x USB 3.1 Gen 1, 4 x USB 2.0, 1 x VGA, 1 x DisplayPort, 1 x RJ-45, 1 x audio line-out, 1 x audio line-in
Power Supply	250W, up to 92% efficient PSU
Optical Drive	Optional DVD-Writer
Chipset	Intel® Q270
