Access panel
To access internal components, you must remove the access panel:
1. Prepare the computer for disassembly (Preparation for disassembly on page 19)
2. Slide the access panel release lever to the left (1) so that it locks into place. Then slide the access panel
back (2) and lift it o the computer (3).
To replace the access panel, reverse the disassembly procedures.
20 Chapter 4 Removal and replacement procedures – Microtower (MT) chassis
