7. Connect the power cable (1) and data cable (2) to the rear of the hard drive.
8. If installing a new drive, connect the opposite end of the data cable to the appropriate system board
connector.
NOTE: You must connect the primary hard drive data cable to the dark blue connector labeled SATA0 to
avoid any hard drive performance problems. If you are adding a second hard drive, connect the data
cable to one of the light blue SATA connectors.
9. Reassemble the computer.
Drives 49
