6. From the front of the computer, remove the Torx T15 screw that secures the assembly to the chassis.
NOTE: Chassis color may vary.
7. Rotate the right side of the assembly away from the computer, and then pull the assembly out of the
front of the chassis while threading the cables through the hole in the front of the chassis.
To reinstall the assembly, reverse the removal procedure.
56 Chapter 4 Removal and replacement procedures – Microtower (MT) chassis
