Quality of Service: Managing Bandwidth More Effectively
Globally-Configured QoS
Table 5-8. IP Precedence-to-802.1p Priority Mapping
Note Using a global IP-Precedence classifier to prioritize IP packets relies on
priorities set in upstream devices and applications.
Figure 5-13 shows the difference between the diffserv bits and precedence
bits in an IPv4 ToS byte and an IPv6 Traffic Class byte. Note that:
■ Precedence bits are a subset of the Differentiated Services bits.
■ The rightmost two bits are reserved.
Figure 5-13. IPv4 ToS/IPv6 Traffic Class Byte with DSCP Codepoint and Precedence Bits
ToS/Traffic Class Byte:
IP Precedence Bits
Corresponding
802.1p Priority
Service Priority Level
000 1 Lowest
001 2 Low
0020Normal
003 3
004 4
005 5
006 6
007 7 Highest
IPv4 Fields: Destination MAC
Address
Source MAC
Address
802.1Q Field Type and
Version
Type-of-Service
Byte
…
Sample IPv4
Packet:
FF FF FF FF FF FF 08 00 09 00 00 16 08 00 45
E 0
...
IPv6 Fields: Destination MAC
Address
Source MAC
Address
...
Traffic Class
Byte
…
Sample IPv6
Packet:
FF FF FF FF FF FF 2001:db8:260:0212::
01b4
...
E 0
...
Differentiated Services Codepoint
Rsvd.
Precedence
Bits
Delay Throughput
Reliability Bits
1 1100000
E 0

HP J8697A Specifications

General

Ports	24
Form Factor	Rack-mountable
Power Supply	Internal
Management	Managed
VLAN Support	Yes
Jumbo Frame Support	Yes
Switching Capacity	48 Gbps
Forwarding Rate	35.7 Mpps
Model	HP J8697A
Port Type	10/100/1000BASE-T
Layer	Layer 2
