11-13

Port Trunking

Port Status and Configuration

Figure 11-7. Example of a Dynamic LACP Trunk with One Standby Link

Using the CLI To Configure a Static or Dynamic Trunk Group

Important Configure port trunking before you connect the trunked links between

switches. Otherwise, a broadcast storm could occur. (If you need to connect

the ports before configuring them for trunking, you can temporarily disable

the ports until the trunk is configured. See “Using the CLI To Configure Ports”

on page 10-10.)

On the switches covered by this guide you can configure up to 24 port trunk

groups having up to 8 links each (with additional standby links if you’re using

dynamic LACP). You can configure trunk group types as follows:

Note Trunks configured as FEC (Fast Ethernet Channel) are not supported. To

configure port trunk groups, use static or LACP trunks. For release notes

describing the latest software updates, visit the ProCurve Networking website

at www.procurve.com. Click on Technical support, and then click on Product

manuals (all).

“Up” Links

Standby Link

Trunk Type Trunk Group Membership

TrkX (Static) DynX (Dynamic)

LACP Yes Yes

Tru nk Yes No
