12-33

Configuring for Network Management Applications

LLDP (Link-Layer Discovery Protocol)

For example, show lldp config produces the following display when the switch

is in the default LLDP configuration:

Figure 12-10. Example of Viewing the General LLDP Configuration

Note: This value corresponds to

the lldp refresh-interval

command (page 12-35).

Med Topology Trap Enabled

-------------------------

False

True

False

True

False
