Port Status and Configuration
Viewing Port Status and Configuring Port Parameters
Using the Menu To Configure Ports.
You can configure and view the port settings by using the menu.
Note The menu interface uses the same screen for configuring both individual ports
and port trunk groups. For information on port trunk groups, refer to Chapter
11, “Port Trunking” .
1. From the Main Menu, Select:
2. Switch Configuration...
2. Port/Trunk Settings
An example of the Menu display is shown below.
Figure 10-2. Example of Port/Trunk Settings with a Trunk Group Configured
2. Press [E] (for E
dit). The cursor moves to the Enabled field for the first port.
3. Refer to the online help provided with this screen for further information
on configuration options for these features.
4. When you have finished making changes to the above parameters, press
[Enter], then press [S] (for S
ave).
===========================- TELNET - MANAGER MODE -=============
Switch Configuration - Port/Trunk Settings
Port Type Enabled Mode Flow Ctrl Group Type
---- --------- + ------- ------------ --------- ----- -----
A1 1000T | Yes Auto-10-100 Disable
A2 1000T | Yes Auto-10-100 Disable
A3 1000T | Yes Auto Disable
A4 1000T | Yes Auto Disable
A5 1000T | Yes Auto Disable
A6 1000T | Yes Auto Disable
A7 1000T | Yes Auto Disable Trk1 Trunk
A8 1000T | Yes Auto Disable Trk2 Trunk
Actions-> Cancel Edit Save Help
Cancel changes and return to previous screen.
Use arrow keys to change action selection and <Enter> to execute ac-
tion.
