10-22
Port Status and Configuration
Viewing Port Status and Configuring Port Parameters
Figure 10-13. Example of Displaying the Current MDI Configuration
Figure 10-14. Example of Displaying the Current MDI Operating Mode
Web: Viewing Port Status and Configuring Port
Parameters
In the web browser interface:
1. Click on the Configuration tab.
2. Click on
[Port Configuration].
3. Select the ports you want to modify and click on
[Modify Selected Ports].
4. After you make the desired changes, click on
[Apply Settings].
Note that the web browser interface displays an existing port trunk group.
However, to configure a port trunk group, you must use the CLI or the menu
interface. For more on this topic, refer to Chapter 11, “Port Trunking” .
Per-Port MDI
Configuration
Per-Port MDI
Operating Mode
