B-15
Monitoring and Analyzing Switch Operation
Status and Counters Data
Figure B-9. Example of the Address Table
To page through the listing, use N
ext page and Prev page.
Finding the Port Connection for a Specific Device on a VLAN. This
feature uses a device’s MAC address that you enter to identify the port used
by that device.
1. Proceeding from figure B-9, press
[S] (for Search), to display the following
prompt:
Enter MAC address: _
2. Type the MAC address you want to locate and press [Enter]. The address
and port number are highlighted if found. If the switch does not find the
MAC address on the currently selected VLAN, it leaves the MAC address
listing empty.
Figure B-10. Example of Menu Indicating Located MAC Address
3. Press
[P] (for Prev page) to return to the full address table listing.
Located MAC
Address and
Corresponding
Port Number
To Next Page
