Removal and replacement procedures 27
4.
Remove the air baffle.
Installing the air baffle
CAUTION: For proper cooling, do not operate the server without the access panel, baffles,
expansion slot covers, or blanks installed. If the server supports hot-plug components, minimize
the amount of time the access panel is open.
1. Insert the air baffle.
2. Install the access panel ("Installing the access panel" on page 24).
3. Close and lock the bezel.
4. Power on the server.
