HP ProLiant ML110 G7 Maintenance And Service Guide

Removal and replacement procedures 45
CAUTION: For proper cooling, do not operate the server without the access panel, baffles,
expansion slot covers, or blanks installed. If the server supports hot-plug components, minimize
the amount of time the access panel is open.
1. Power down the server (on page 23).
2. Remove the access panel ("Removing the access panel" on page 24).
3. Remove the air baffle ("Removing the air baffle" on page 26).
4. Remove the full-length expansion board retainer, if any full-length expansion boards are installed
("Removing the full-length expansion board retainer" on page 43).
5. Push out to remove the slot cover.
Installing an expansion board
1. Power down the server (on page 23).
2. Remove the access panel ("Removing the access panel" on page 24).
3. Remove the air baffle ("Removing the air baffle" on page 26).
4. Remove the full-length expansion board retainer, if any full-length expansion boards are installed
("Removing the full-length expansion board retainer" on page 43).
5. Remove the expansion slot cover ("Removing an expansion slot cover" on page 44).

HP ProLiant ML110 G7 Specifications

General

Product Type	Server
Form Factor	Tower
Processor Sockets	1
Chipset	Intel C202
Memory Type	DDR3 UDIMM
Maximum Memory	16 GB
Memory Slots	4
Processor	Intel Xeon E3-1200 series
Storage	SAS or SATA
Drive Bays	4 LFF or 8 SFF
Hard Drives	Optional
Optical Drive	Optional
Network Controller	HP NC112i Gigabit Ethernet Adapter (1 port)
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server
Storage Controller	HP Dynamic Smart Array B120i
