Removal and replacement procedures 47
5.
Remove the BBWC module.
6. If the BBWC module is connected to a battery pack, disconnect the pack cable from the connector on
the top of the cache module.
CAUTION: To prevent damage to the cache module during installation, be sure the cache
module is fully inserted before pressing down.
Removing the BBWC battery pack
1. Back up all data.
2. Close all applications.
3. Power off the server ("Power down the server" on page 23).
