Removal and replacement procedures 53
7.
Remove the FBWC module.
8. If the FBWC module is connected to a capacitor pack, disconnect the capacitor pack cable from the
connector on the top of the cache module.
CAUTION: To prevent damage to the cache module during installation, be sure the cache
module is fully inserted before pressing down.
