Server Component Identification 15
Item Description
7 Processor 2 heatsink connector
8 Power button/LED connector
9 SATA 1 connector
10 SATA 2 connector
11 Primary SCSI connector
12 Secondary SCSI connector
13 PPM 2 socket
14 RILOE II connector (30-pin)
15 Serial port connector
16 64-bit, 66-MHz PCI-X slot, bus 2
17 64-bit, 133-MHz PCI-X slot, bus 6
18 64-bit, 100-MHz PCI-X slot, bus 9
19 64-bit, 100-MHz PCI-X slot, bus 9
20 System maintenance switch
21 System battery
22 PCI Express x4 slot (full-length card)
23 PCI Express x4 slot (full-length card)
24 NMI switch
25 Redundant fan connector
26 System fan connector
27 DIMM slot 6 (Bank C)
28 DIMM slot 5 (Bank C)
29 DIMM slot 4 (Bank B)
30 DIMM slot 3 (Bank B)
31 DIMM slot 2 (Bank A)
