HP ProLiant ML350 Generation 4p User Manual

16 HP ProLiant ML350 Generation 4p Server User Guide
Item Description
32 DIMM slot 1 (Bank A)
NMI Jumper
The NMI jumper allows administrators to perform a memory dump before
performing a hard reset. Crash dump analysis is an essential part of eliminating
reliability problems, such as hangs or crashes in operating systems, device
drivers, and applications. Many crashes freeze a system, requiring you to do a
hard reset. Resetting the system erases any information that would support root
cause analysis.
Systems running Microsoft® Windows® operating systems experience a blue
screen trap when the operating system crashes. When this happens, Microsoft®
recommends that system administrators perform an NMI event by pressing a
dump switch. The NMI event enables a hung system to become responsive again.
System Maintenance Switch
Position Default Function
S1 iLo
Security
Off = iLO security is enabled
On = iLO security is disabled
S2 Off Off = System configuration can be
changed.
On = System configuration is
locked.
S3 Off Reserved
S4 Off Reserved
S5 Off Off = Power-on password is
enabled.
On = Power-on password is
disabled.
S6 Off Off = No function
On = Clear NVRAM

HP ProLiant ML350 Generation 4p Specifications

General

Processor Socket	Socket 604
Chipset	Intel E7520
Form Factor	Tower
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server
Processor	Intel Xeon
Memory	PC2-3200 DDR2 SDRAM
Memory Slots	8
Storage	SAS or SATA (depending on configuration)
Drive Bays	Up to 8 hot-plug drive bays
Network	Embedded NC7782 PCI-X Gigabit Server Adapter
Power Supply	Redundant power supply optional
Expansion Slots	6 total: 2 PCI-Express, 2 PCI-X
