Hardware Options Installation 57
3. Install the drive.
NOTE: Depending on model purchased, the server may look slightly
different than shown.
4. Determine the status of the drive by observing the drive LEDs ("SATA or
SAS Hard Drive LEDs" on page 24
).
5. Resume normal server operations.
Removable Media Device Options
Identifying Guide Screws (on page 58)
Accessing the Removable Media Cage (on page 58)
Removing Shipping Brackets (on page 59
)
Installing a Half-Height or Full-Height Media Device Option (on page 60
)
Installing a Tape Drive Option (on page 62
)
Installing an Internal Two-Bay Hot-Plug SCSI Drive Cage Option ("Installing a
Tape Drive Option" on page 62
)
