58 HP ProLiant ML350 Generation 4p Server User Guide
Identifying Guide Screws
When installing drives in the removable media bay, guide screws must be
installed to make sure the drives correctly align in the drive cage. HP has
provided extra guide screws. They are located behind the side access panel of the
server. Some options use 5.25 M3 metric screws and some use HD 6-32 screws.
The metric screws supplied by HP are black.
Accessing the Removable Media Cage
The server supports installation of optional internal storage devices.
IMPORTANT: HP and Compaq branded SCSI non-hot-plug cables are
terminated. Remove all terminating jumpers from third-party SCSI
devices before installing them in the server.
1. Power down the server ("Powering Down the Server" on page 25).
2. Extend the server from the rack, if applicable ("Extending the Server from
the Rack" on page 26
).
3. Remove the front bezel door, if necessary ("Removing the Front Bezel
(Tower Model)" on page 27
).
4. Remove the access panel ("Removing Access Panel" on page 27
).

HP ProLiant ML350 Generation 4p Specifications

General

Processor Socket	Socket 604
Chipset	Intel E7520
Form Factor	Tower
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server
Processor	Intel Xeon
Memory	PC2-3200 DDR2 SDRAM
Memory Slots	8
Storage	SAS or SATA (depending on configuration)
Drive Bays	Up to 8 hot-plug drive bays
Network	Embedded NC7782 PCI-X Gigabit Server Adapter
Power Supply	Redundant power supply optional
Expansion Slots	6 total: 2 PCI-Express, 2 PCI-X
