HP ProLiant ML350 Generation 4p User Manual

79
Server Cabling
In This Section
Cabling Guidelines .......................................................................................................................79
SCSI Hot-Plug Cabling ................................................................................................................79
Connecting ATA or ATAPI Devices to the Integrated IDE Controller........................................92
Cabling Guidelines
This chapter provides an overview of the internal cabling of the HP ProLiant
ML350 Generation 4 Performance (G4p) server chassis. It also includes
information on how to cable SCSI, SATA, SAS, IDE, and removable media
devices in the system, as well as information about all critical system cabling. If
external cabling is required, refer to the documentation included with the external
storage device.
SCSI Hot-Plug Cabling
Storage Device Installation (on page 79)
Identifying SCSI Components (on page 80
)
Installing an Internal-to-External SCSI Controller ("Connecting ATA or ATAPI
Devices to the Integrated IDE Controller" on page 92
)
Cabling SmartArray or other RAID Controller ("Installing an Internal-to-
External SCSI Connector" on page 87
)
Cabling SCSI Devices in the Removable Media Area (on page 89
)
Storage Device Installation Guidelines
Consider the following guidelines when adding SCSI devices:

HP ProLiant ML350 Generation 4p Specifications

General

Processor Socket	Socket 604
Chipset	Intel E7520
Form Factor	Tower
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server
Processor	Intel Xeon
Memory	PC2-3200 DDR2 SDRAM
Memory Slots	8
Storage	SAS or SATA (depending on configuration)
Drive Bays	Up to 8 hot-plug drive bays
Network	Embedded NC7782 PCI-X Gigabit Server Adapter
Power Supply	Redundant power supply optional
Expansion Slots	6 total: 2 PCI-Express, 2 PCI-X
