Hardware Options Installation 67
3. Slide the power supply into the power supply bay, then apply pressure to the
power supply until the release/lock lever clicks the power supply securely
into the bay.
4. Connect the power cords to the power supplies.
5. Be sure that the power supply and redundant power supply LEDs are
illuminated green.
Expansion Board Options
The server supports PCI, PCI-X, and PCI Express expansion boards.
For instructions on installing a RILOE II board, refer to the HP Remote Insight
Lights-Out Edition II User Guide on the Documentation CD.
IMPORTANT: It is recommended that the optional RILOE II board be
installed in slot 6. If you plan to install a RILOE II board in the future,
leave slot 6 unpopulated.
Removing the Expansion Slot Cover
1. Power down the server ("Powering Down the Server" on page 25).
2. Extend the server from the rack, if applicable ("Extending the Server from
the Rack" on page 26
).
3. Remove the front bezel door, if necessary ("Removing the Front Bezel
(Tower Model)" on page 27
).
4. Remove the access panel ("Removing Access Panel" on page 27
).
