HP ProLiant ML350 Generation 4p User Manual

Server Cabling 87
68-to-50 Pin SCSI Adapter
If installing a device that uses a Fast SCSI-2 interface, you must provide a 68-to-
50 pin SCSI adapter. This adapter should be installed between the 50-pin
interface on the device and the 68-pin SCSI cable connected to the SCSI channel
on the system board.
Installing an Internal-to-External SCSI Connector
If you are not using one or both SCSI channels (primary or secondary) internally
or you install a SCSI or SmartArray option card, you may install an internal-to-
external SCSI connector in the SCSI knockout locations on the rear of the
chassis.
For installation instructions, refer to the VHDCI or HD68 SCSI Cable ("VHDCI
or HD68 SCSI Cable Option" on page 70
) section in this guide.
Cabling SCSI SmartArray or other RAID Controller
Many configurations are possible when SCSI controllers are added. This section
outlines the procedure for connecting internal hard drives to a SCSI controller
option or a SmartArray controller and assumes that the controller option or
SmartArray controller is already installed.

HP ProLiant ML350 Generation 4p Specifications

General

Processor Socket	Socket 604
Chipset	Intel E7520
Form Factor	Tower
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server
Processor	Intel Xeon
Memory	PC2-3200 DDR2 SDRAM
Memory Slots	8
Storage	SAS or SATA (depending on configuration)
Drive Bays	Up to 8 hot-plug drive bays
Network	Embedded NC7782 PCI-X Gigabit Server Adapter
Power Supply	Redundant power supply optional
Expansion Slots	6 total: 2 PCI-Express, 2 PCI-X
