Hardware Options Installation 49
9. Connect the heatsink connector to the connector on the system board.
Item Description
1 Processor 1 heatsink connector
2 Processor 2 heatsink connector
10. Open the latches on the corresponding PPM slot.
11. Install the PPM for processor 2 (if installing a second processor).
NOTE: PPM 1 is embedded onto the system board.
