2. Remove the rear cover (see Rear cover on page 30).
The optical disc drive can now be seen in the upper left side of the chassis.
3. Loosen the captive screw (1) through the optical disc drive bracket that secures the optical disc
drive to the chassis.
NOTE: The optical disc drive bracket is installed on the chassis if the model does not have an
optical disc drive. Remove the bracket from the chassis and follow the remaining steps using two
screws from the option kit to mount the bracket to the optical disc drive.
4. Slide the optical disc drive left (2) to remove it from the chassis.
Replacing drives
41
