HP UPS Management Module web interface 42

HP UPS Management Module web interface

overview

The web interface graphically displays various measurements and warning and alarm messages from the

management module. Also, system values and power fail settings can be configured through the web

interface and sent to the management module.

NOTE: All status information and configuration parameters included on the HP UPS

Management Module web interface are available using the HP UPS Management Module

Service Menu (on page 82).

Accessing the web interface

You can access the web interface:

• Remotely through a Web browser (on page 42)

• Locally from the system tray icon (on page 43) in Windows®

Web browser

Use a web browser to access the HP UPS Management Module web interface:

1. If necessary, configure the management module by:

a. Launching a terminal emulation program (on page 21).

b. Configuring the management module for remote access (on page 22).

2. Be sure that you have connected the network cable ("Connecting the network cable" on page 20) to

the management module.

3. Press the Reset button on the management module front panel. The management module discovers

attached UPSs.

4. Launch a supported browser. The browser window appears.

5. In the Address field (Microsoft® Internet Explorer) or the Location field (Mozilla and Firefox), enter:

http://xxx.xxx.xxx.xxx

-or-

https://xxx.xxx.xxx.xxx

where xxx.xxx.xxx.xxx is the IPv4 or IPv6 address. The log in screen appears.

6. Sign in through the web browser ("Signing in to the web interface" on page 43).

NOTE: For a complete list of the browser requirements, see "Web interface requirements (on

page 15)."
