102
Table 114 Restore Image Page item description
Item Descri
tion
Download via TFTP Enables to download files via TFTP.
Download via HTTP Enables to download files via HTTP.
TFTP Server IP Address
Specifies the TFTP Server IP Address from which the image files are
downloaded.
Source File Name
Specifies file name for the downloaded image file. Click Browse to locate
the image file on your computer.
Activating Image Files
The Active Image Page allows network managers to select and reset the Image files.
Click Administration Firmware Upgrade Active Image. The Active Image Page opens.
Figure 145 Active Image Page
The Active Image Page contains the following fields:
Table 115 Active Image Page item description
Item Descri
tion
Active Image After Reset
Selects the image file to be active on the unit after the switch is reset. The
possible field values are:
Current Image: Activates the current image after the switch is reset.
Backup Image: Activates backup image after the switch is reset.
Managing System Logs
This section provides information for managing system logs. The system logs enable viewing switch events
in real time, and recording the events for later usage. System Logs record and manage events and report
errors and informational messages. Event messages have a unique format, as per the system Log protocols
recommended message format for all error reporting. For example, system Log and local device reporting
messages are assigned a severity code, and include a message mnemonic, which identifies the source
application generating the message. It allows messages to be filtered based on their urgency or relevancy.
Each message severity determines the set of event logging devices that are sent per each event message.
The following table lists the log severity levels:
