31
Item Descri
tion
Flow Control
Displays the flow control status on the port. The possible field values are:
Enabled: Enables flow control on the port.
Disabled: Disables flow control on the port.
Speed
Displays the configured rate for the port. The port type determines what speed setting
options are available. Port speeds can only be configured when auto negotiation is
disabled. The possible field values are:
Auto: Use to automatically configure the port.
10M: Indicates the port is currently operating at 10 Mbps.
100M: Indicates the port is currently operating at 100 Mbps.
1000M: Indicates the port is currently operating at 1000 Mbps.
Duplex
Displays the port duplex mode. The port speed is set to 10M or 100M or 1000M per
second. The possible field values are:
Auto: Use to automatically configure the port.
Full: The interface supports transmission between the switch and its link partner in
both directions simultaneously.
Half: The interface supports transmission between the switch and the client in only
one direction at a time.
PVID Indicates VLAN ID of this port for untagged packets.
Viewing Port Details
The Port Detail Page displays the current port configuration for specific ports.
Click Port Administration Detail. The Port Detail Page opens.
Figure 70 Port Detail Page
Configuring PoE
Power over Ethernet (PoE) provides power to devices over existing LAN cabling, without updating or
modifying the network infrastructure. Power over Ethernet removes the necessity of placing network devices
next to power sources.
CAUTION:
PoE is only supported by V1905-24-PoE Switch.
This section contains the following topics:
