HP V1905 Series User Manual

62
Item Descri
p
tion
Action
Indicates the ACL forwarding action. In addition, the port can be shut down, a trap
can be sent to the network administrator, or packet is assigned rate limiting
restrictions for forwarding.
Configuring ACL Binding
This section includes the following topics:
 Defining ACL Binding
 Removing ACL Binding
 Viewing ACL Binding
Defining ACL Binding
The ACL Binding Setup Page allows the network administrator to bind specific ports to MAC or IP based
ACLs.
Click Device  ACL  ACL Binding  Setup. The ACL Binding Setup Page opens.
Figure 99 ACL Binding Setup Page
The ACL Binding Setup Page contains the following fields:
Table 79 ACL Binding Setup Page item description
Item Descri
p
tion
Bind ACL Assigns ACL type
Select ACL Selects the ACL from a list of previously defined ACLs to which the port can be bound.
Removing ACL Binding
The ACL Binding Remove Page allows the network administrator to remove user-defined ACLs from a
selected interface.
Click Device  ACL  ACL Binding  Remove. The ACL Binding Remove Page opens.

HP V1905 Series Specifications

General

Model	HP V1905 Series
VLAN Support	No
QoS	No
Management	Unmanaged
Jumbo Frame Support	No
Type	Unmanaged
Ports	8, 16, 24, or 48 ports
Uplink Ports	Gigabit uplink ports
MAC Address Table Size	4K entries
Power Consumption	Varies by model
Dimensions	Varies by model
Weight	Varies by model
Operating Temperature	0°C to 40°C
Operating Humidity	10% to 90% non-condensing
