93
Item Descri
tion
NORMAL: The user on the port passed the authentication.
BLOCK: The port is in the initial state after the LDB feature is enabled or
the port is aged out.
SLEEP: The number of the user’s authentication attempts exceeded the
preset maximum value.
User Displays the user passing the authentication.
MAC Displays the MAC address of the user passing the authentication.
Configuring Broadcast Storm Control
Broadcast Storm Control limits the amount of Multicast and Broadcast frames accepted and forwarded by
the switch. When Layer 2 frames are forwarded, Broadcast and Multicast frames are flooded to all ports on
the relevant VLAN. This occupies bandwidth, and loads all nodes on all ports.
A Broadcast Storm is a result of an excessive amount of broadcast messages simultaneously transmitted
across a network by a single port. Forwarded message responses are heaped onto the network, straining
network resources or causing the network to time out.
Broadcast Storm is enabled for all Gigabit ports by defining the packet type and the rate the packets are
transmitted. The system measures the incoming Broadcast and Multicast frame rates separately on each port,
and discards the frames when the rate exceeds a user-defined rate.
Packet threshold is ignored if Broadcast Storm Control is disabled.
This section contains the following topic:
Defining Broadcast Storm Control
Viewing Broadcast Storm Control
Defining Broadcast Storm Control
The Broadcast Storm Setup Page allows network managers to define Broadcast Storm Traffic.
Click Device Broadcast Storm Setup. The Broadcast Storm Setup Page opens.
Figure 134 Broadcast Storm Setup Page
The Broadcast Storm Setup Page contains the following fields:
