HP V1905 Series User Manual

77
Table 96 SNMP Communities Setup Page item description
Item Descri
p
tion
SNMP Status
Specifies if SNMP is enabled on the switch. The possible field values are:
 Enabled: Enables SNMP on the switch.
 Disabled: Disables SNMP on the switch.
Insert New Community Enables adding an SNMP community.
Standard
Selects pre-defined community strings. The possible field values are:
 Public: Displays the pre-defined public community string name.
 Private: Displays the pre-defined private community string name.
User Defined Defines a user-defined community string name.
Access Mode
Defines the access rights of the community. The possible field values are:
 Read Only: Management access is restricted to read-only, and changes cannot
be made to the community.
 Read Write: Management access is read-write and changes can be made to the
switch configuration, but not to the community.
Removing SNMP Communities
The SNMP Communities Remove Page allows the system manager to remove SNMP Communities.
Click Administration  SNMP  Communities  Remove. The SNMP Communities Remove Page opens.
Figure 119 SNMP Communities Remove Page
To Remove SNMP Communities:
1. Select the SNMP Communities.
2. Click Remove.
Defining SNMP Traps
The SNMP Traps Setup Page allows the system manager to defining filters that determine whether traps are
sent to specific users, and the trap type sent.
Click Administration  SNMP  Traps  Setup. The SNMP Traps Setup Page opens.

HP V1905 Series Specifications

General

Model	HP V1905 Series
VLAN Support	No
QoS	No
Management	Unmanaged
Jumbo Frame Support	No
Type	Unmanaged
Ports	8, 16, 24, or 48 ports
Uplink Ports	Gigabit uplink ports
MAC Address Table Size	4K entries
Power Consumption	Varies by model
Dimensions	Varies by model
Weight	Varies by model
Operating Temperature	0°C to 40°C
Operating Humidity	10% to 90% non-condensing
