HP V1905 Series User Manual

38
Modifying Port VLAN Settings
The Modify Port VLAN Page allows the network manager to modify port VLAN settings.
Click Device  VLAN  Modify Port. The Modify Port VLAN Page opens.
Figure 76 Modify Port VLAN Page
The Modify Port VLAN Page contains the following fields:
Table 62 Modify Port VLAN Page item description
Item Descri
p
tion
Select membership type
Selects the membership type for each port on the VLAN. The possible field values
are:
 Untagged: Indicates the interface is an untagged member of the VLAN.
 Tagged: Indicates the interface is a tagged member of a VLAN. VLAN tagged
frames are forwarded by the interface. The frames contain VLAN information.
 Not A Member: Indicates the interface is not a member of the VLAN.
 Not available for selection: Indicates the interface is not available for selection.
VLAN ID Defines the VLAN ID to which the port is to be assigned.
Renaming VLANs
The VLAN Rename Page allows the network manager to select a VLAN from the list to be renamed.
Click Device  VLAN  Rename. The VLAN Rename Page opens.
Figure 77 VLAN Rename Page

HP V1905 Series Specifications

General

Model	HP V1905 Series
VLAN Support	No
QoS	No
Management	Unmanaged
Jumbo Frame Support	No
Type	Unmanaged
Ports	8, 16, 24, or 48 ports
Uplink Ports	Gigabit uplink ports
MAC Address Table Size	4K entries
Power Consumption	Varies by model
Dimensions	Varies by model
Weight	Varies by model
Operating Temperature	0°C to 40°C
Operating Humidity	10% to 90% non-condensing
