HP V1905 Series User Manual

32
 Defining Port PoE
 Viewing PoE
Defining Port PoE
The Port PoE Setup Page allows the network manager to configure port PoE settings.
Click Port  PoE  Setup. The Port PoE Setup Page opens.
Figure 71 Port PoE Setup Page
The Port PoE Setup Page contains the following fields:
Table 57 Port PoE Setup Page item description
Item Descri
p
tion
PoE State
Defines the port PoE state. The possible values are:
 Enable: Enables the port for PoE. This is the default.
 Disable: Disables the port for PoE.
Power Mode
Defines the power mode for the selected port. The possible values are:
 Normal: The port can provide 25W power for access device max. This is the
default.
 High Power: The port can provide 30W power for access device max
PoE Mode for selected &
enabled ports
Defines the PoE mode for the selected port.
Guarantee Power
Summary
Displays guaranteed and total PoE power:
 Total PoE Available: The total amount of PoE power that can be provided by
the switch.
 Guarantee PoE: The maximum amount of PoE power that has been guaranteed
for selected ports. This value is defined by the number of ports you have set to
Guarantee.
 Remaining (Available - Guarantee): The minimum amount of non-guaranteed
PoE power left over after allocating the Guarantee PoE power. This value is a
guideline for assigning guarantee ports. The actual amount of power used and
available is displayed on the Port PoE Summary page.
