HP V1905 Series User Manual

105
Table 118 Logging Display Page item description
Item Descri
p
tion
Save Preview Saves the displayed Log table to a Web (html) page.
Clear Logs Clears all logs
Log Time Displays the time at which the log was generated.
Severity Displays the log severity.
Description Displays the log message text.
Managing Switch Diagnostics
This section contains information for viewing and configuring port and cable diagnostics, and includes the
following topics:
 Configuring Port Mirroring
 Configuring Cable Diagnostics
Configuring Port Mirroring
Port mirroring monitors and mirrors network traffic by forwarding copies of incoming and outgoing packets
from one port to a monitoring port. Port mirroring can be used as a diagnostic tool as well as a debugging
feature. Port mirroring also enables switch performance monitoring.
Network administrators can configure port mirroring by selecting a specific port from which to copy all
packets, and other ports to which the packets copied.
This section contains the following topics:
 Defining Port Mirroring
 Removing Port Mirroring
Defining Port Mirroring
The Port Mirroring Setup Page contains parameters for configuring port mirroring.
Click Monitoring  Port Mirroring  Setup. The Port Mirroring Setup Page opens.
Figure 148 Port Mirroring Setup Page
The Port Mirroring Setup Page contains the following fields:

HP V1905 Series Specifications

General

Model	HP V1905 Series
VLAN Support	No
QoS	No
Management	Unmanaged
Jumbo Frame Support	No
Type	Unmanaged
Ports	8, 16, 24, or 48 ports
Uplink Ports	Gigabit uplink ports
MAC Address Table Size	4K entries
Power Consumption	Varies by model
Dimensions	Varies by model
Weight	Varies by model
Operating Temperature	0°C to 40°C
Operating Humidity	10% to 90% non-condensing
