HP V1905 Series User Manual

69
Table 88 DSCP to Queue Summary Page item description
Item Descri
p
tion
DSCP Displays the incoming packet’s DSCP value.
CoS
Indicates the CoS value forwarding queue to which the DSCP priority is mapped. The
possible field values are 0-7.
Configuring Trust Mode
The Trust Setup Page contains information for configuring trust mode on the switch.
Click Device  QoS  Trust  Setup. The Trust Setup Page opens.
Figure 109 Trust Setup Page
The Trust Setup Page contains the following fields:
Table 89 Trust Setup Page item description
Item Descri
p
tion
Trust Mode
Specifies which packet fields to use for classifying packets entering the switch. When
no rules are defined, the traffic containing the predefined packet CoS field is
mapped according to the relevant trust modes table. Traffic not containing a
predefined packet field is mapped to “best effort”. The possible Trust Mode field
values are:
 CoS: Classifies traffic based on the CoS tag value.
 DSCP: Classifies traffic based on the DSCP tag value.
Configuring Bandwidth Settings
Defining Bandwidth Settings
The Bandwidth Setup Page allows network managers to define the bandwidth settings for a specified
interface.
Click Device  QoS  Bandwidth  Setup. The Bandwidth Setup Page opens.

HP V1905 Series Specifications

General

Model	HP V1905 Series
VLAN Support	No
QoS	No
Management	Unmanaged
Jumbo Frame Support	No
Type	Unmanaged
Ports	8, 16, 24, or 48 ports
Uplink Ports	Gigabit uplink ports
MAC Address Table Size	4K entries
Power Consumption	Varies by model
Dimensions	Varies by model
Weight	Varies by model
Operating Temperature	0°C to 40°C
Operating Humidity	10% to 90% non-condensing
