70
Figure 110 Bandwidth Setup Page
The Bandwidth Setup Page contains the following fields:
Table 90 Bandwidth Setup Page item description
Item Descri
p
tion
Ingress
Rate Limit
Enable
Ingress Rate
Limit
Enables setting an Ingress Rate Limit.
Ingress Rate
Limit
Defines the ingress traffic limit for the port. The field range of normal port is 3500
- 100,000 kbits per second, and the field range of combo port is 3500 -
1,000,000 kbits per second.
Egress
Shaping
Rates
Enable
Egress
Shaping
Rate
Enables setting Egress Shaping Rates.
Committed
Information
Rate (CIR)
Defines the CIR for the interface. The field range of normal port is 64 - 100,000
kbits per second, and the field range of combo port is 64 - 1,000,000 kbits per
second.
Committed
Burst Size
(CbS)
Defines the CbS for the interface. The field range is 4,096 bytes - 133,120 bytes
per second.
Viewing Bandwidth Settings
The Bandwidth Summary Page displays bandwidth settings for a specified interface.
Click Device QoS Bandwidth Summary. The Bandwidth Summary Page opens.
