28
Figure 67 Port Summary Page
The Port Summary Page contains the following fields:
Table 54 Port Summary Page item description
Item Descri
p
tion
State
Filters the list of MAC addresses displayed according to the type of MAC address
configuration. Possible values are:
 All: Displays all MAC addresses.
 Static: Displays the statically configured MAC addresses.
 Dynamic: Displays the dynamically learned MAC addresses.
MAC Address
Displays the current MAC addresses listed in the MAC address table, filtered by
the selected value of the State field.
VLAN ID Displays the VLAN ID associated with the port and MAC address.
State
Displays the MAC address configuration method. Possible values are:
 Config Static: Displays the statically configured MAC address.
 Config Dynamic: Displays the dynamically learned MAC address.
Port Index Displays the port through which the address was learned.
Aging Time
Displays that the MAC address is aged out or not. Possible values are:
 NOAGED: Indicates that the MAC address is not aged out.
 AGING: Indicates that the MAC address is aged out.
Configuring Port
This section includes the following topics:
 Configuring Port Basic Settings
 Configuring PoE
 Viewing Port Statistics
Configuring Port Basic Settings
This section contains information for configuring Port Basic Settings, and includes the following topics:
