15
Menu Item Descri
tion
Device
VLAN
Contains tabs that allow you to:
Create a VLAN.
Modify a VLAN.
Modify VLAN membership for a port.
Rename a VLAN.
Remove a VLAN.
Display VLAN membership for a port.
Display VLAN information.
Spanning Tree
Allows you to configure a Spanning Tree Protocol.
Contains tabs that allow you to:
Display selected spanning tree information for every port.
Display individual port spanning tree information.
Modify the spanning tree settings for a port.
IGMP Snooping
Allows you to enable or disable IGMP snooping and IGMP query
modes.
Broadcast Storm Allows you to enable or disable broadcast control.
ACL Configures the ACL.
MAC Based ACL Configures MAC Based ACL on the switch.
IP Based ACL Configures IP Based ACL on the switch.
ACL Binding Configures ACL Binding on the switch.
QoS Configures QoS settings.
CoS
Contains tabs that allow you to:
Displays CoS default settings assigned to ports.
Defines CoS
Queue Configures Queue Setting.
CoS to Queue Displays and defines CoS to Queue.
DSCP to Queue Contains fields for mapping DSCP settings to traffic queues.
Trust Configures Trust Settings.
Bandwidth Displays and defines Bandwidth Settings.
VoIP Traffic Setting
Contains tabs that allow you to:
Display Voice VLAN summary.
Configure Voice VLAN global settings.
Configure Voice VLAN port settings.
Display port information for Voice VLAN.
Display OUI summary.
Add or remove OUI.
LLDP Allows you to configure LLDP global and port settings.
