HP V1905 Series User Manual

22
 Removing ARP Entries
 Viewing ARP Settings
Defining ARP Settings
The ARP Settings Setup Page allows network managers to define ARP parameters for specific interfaces.
Click Administration  ARP Settings  Setup. The ARP Settings Setup Page opens.
Figure 59 ARP Settings Setup Page
The ARP Settings Setup Page contains the following fields:
Table 49 ARP Settings Setup Page item description
Item Descri
p
tion
Interface Indicates the management VLAN (VLAN 1) for which ARP parameters are defined.
IP Address Defines the static IP address, which is associated with the static MAC address.
MAC Address Defines the static MAC address, which is associated with the static IP address.
ARP Entry Age Out
Specifies the aging time for dynamic ARP entries. After the ARP Entry Age,
dynamic ARP entries are deleted from the table. The range is 1-40000000. The
default value is 1200 seconds.
Removing ARP Entries
The ARP Entries Remove Page provides parameters for removing ARP entries from the ARP Table.
Click Administration  ARP Settings  Remove. The ARP Entries Remove Page opens.

HP V1905 Series Specifications

General

Model	HP V1905 Series
VLAN Support	No
QoS	No
Management	Unmanaged
Jumbo Frame Support	No
Type	Unmanaged
Ports	8, 16, 24, or 48 ports
Uplink Ports	Gigabit uplink ports
MAC Address Table Size	4K entries
Power Consumption	Varies by model
Dimensions	Varies by model
Weight	Varies by model
Operating Temperature	0°C to 40°C
Operating Humidity	10% to 90% non-condensing
