HP Z800 Service Manual

Table 6-10 POST error messages (continued)
Screen message Probable cause Recommended action
514—Memory fan not
detected
Memory fan missing, disconnected, or
defective.
1.
Verify that the memory fan is installed and
connected properly.
2.
Replace the fan.
515—CPU Overtemp ocurrred Insufficient processor cooling or
processor defect.
1.
If necessary, add a heatsink to the processor and
ensure proper operation.
2.
Replace the processor.
516—Chipset fan not detected Chipset fan missing, disconnected, or
defective.
1.
Ensure that the fan is installed and connected
properly.
2.
Replace the fan.
517—Low power CPU
heatsink(s) detected for high
power CPUs
Inadequate heatsink is installed. Replace the low power heatsink with a high power
heatsink.
518—Power supply wattage
insufficient for hardware
configuration
Workstation configuration requires
more power than the power supply
can provide.
●
Reduce the workstation power consumption.
●
Replace the power supply with a high output
power supply.
601—Diskette Controller Error Diskette controller circuitry or diskette
drive circuitry incorrect.
1.
Run the Computer Setup (F10) utility.
2.
Verify cabling and replace defective cables if
necessary.
3.
Clear CMOS.
4.
Replace the diskette drive.
5.
Replace the system board.
605—Diskette Drive Type
Error
Mismatch in drive type.
1.
Run the Computer Setup (F10) Utility.
2.
Disconnect any other diskette controller devices
(tape drives).
3.
Clear the CMOS.
610—External Storage Device
Failure
External storage device is not
detected, is improperly connected, or
is defective.
1.
Verify that the external device is present and
connected properly.
2.
Replace the external device.
611—Primary Floppy Port
Address Assignment Conflict
The flexible disk drive is configured at
a previously assigned address.
Select a new address for the flexible disk drive.
912—Computer Cover Has
Been Removed Since Last
System Start Up
N/A No action required.
913—Front 1394 Not
Connected
Front 1394 device cable is
disconnected from the system board.
Reconnect the 1394 cable and restart.
916—Power Button Not
Connected
Power button cable is disconnected
from the system board.
Reconnect the cable and restart.
917—Front Audio Not
Connected
Front audio mechanism is missing or is
not connected.
1.
Reconnect or replace the front audio cable.
2.
Reconnect or replace the front audio mechanism.
ENWW
Diagnostic codes and errors
253

HP Z800 Specifications

General

Processor cache	8 MB
Processor model	E5560
Processor frequency	2.8 GHz
Processor cache type	L2
Processor manufacturer	Intel
Processor front side bus	1333 MHz
Number of processors installed	2
Audio system	Integrated High Definition Realtek ALC262 Audio, optional Creative X-Fi Titanium PCIe Audio Card, optional HP Thin USB Powered Speakers
Product type	Workstation
Motherboard chipset	Intel® 5520
ECC	Yes
Maximum internal memory	192 GB
HDD speed	15000 RPM
HDD capacity	446 GB
HDD interface	Serial Attached SCSI (SAS)
Optical drive type	DVD Super Multi
Card reader integrated	No
I/O ports	Front: 3 USB 2.0, 1 IEEE 1394a, 1 microphone in, 1 headphone out; Rear: 6 USB 2.0, 1 IEEE 1394a, 1 audio in, 1 audio out, 1 microphone in, 2 PS/2, 2 RJ-45 to integrated Gigabit LAN, 1 serial; Internal: 3 USB 2.0
Headphone outputs	1
USB 2.0 ports quantity	9
Parallel ports quantity	0
Power supply	1110 W
Power consumption (typical)	240 W
Non-operating altitude	9100 m
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	8 - 90 %
Operating relative humidity (H-H)	8 - 85 %
Display	HP LP1965 19-inch LCD Monitor, HP LP2065 20-inch LCD Monitor, HP LP2275w 22-inch Widescreen LCD Monitor, HP LP2475w 24-inch Widescreen LCD Monitor, HP DreamColor LP2480zx Professional Display (24-inch widescreen), HP LP3065 30-inch Widescreen LCD Monitor (all sold separately)
Drive bays	3 external 5.25\
Graphics card	-
Keyboard type	HP PS/2 Standard Keyboard
Expansion slots	1 PCI, 1 PCI Express Gen1 (x8 mechanically, x4 electrically), 1 PCI Express Gen2 (x8 mechanically, x4 electrically), 2 PCI Express Gen2 (x16 mechanically, x8 electrically), 2 PCI Express Gen2 x16
Pointing device	HP USB Laser Scroll Mouse
Power requirements	1110 watts wide-ranging, active Power Factor Correction, direct connection Power Supplies
Storage drive type	300 GB 15000 rpm SAS 146 GB 15000 rpm SAS SAS 146 GB + 300 GB
HDD controller type	SATA (10000 rpm) SATA (7200 rpm) SAS (15000 rpm)
Video card features	No integrated Graphic Card
Maximum HDD capacity	450 GB
Storage drive controller	Integrated 6 channel SATA 3 Gb/s controller with RAID (0, 1, 5 or 10) capability, integrated 8 channel SAS controller with RAID (0, 1 or 10) capability, optional LSI 8888 ELP 8-port SAS HW with RAID (0, 1, 5 or 10) capability
Minimum storage drive space	146 GB
Operating system installed	Windows Vista Business
Compatible operating systems	HP Installer Kit for Linux
Chassis type	Mini Tower
Country of origin	China

Weight and Dimensions

Depth	526.5 mm
Width	203.5 mm
Height	445.1 mm
Weight	19500 g
