Table 6-10 POST error messages (continued)
Screen message Probable cause Recommended action
1802—Processor Not
Supported
The system board does not support the
processor.
Replace the processor with a compatible one.
1803—Processor feature set is
insufficient for current system
settings
Processor feature set is insufficient for
current system settings. The BIOS
settings do not match the support
provided by the processor
Change the BIOS settings or upgrade the processors.
1804—A processor feature
and the memory configuration
are incompatible
A processor feature is incompatible
with the memory configuration.
Restore the previous memory configuration.
ERROR: invalid 1394 GUID BIOS installed incorrect UUID for the
IEEE-1394 interface.
Replace the system board.
ERROR: Invalid electronic
serial number
No electronic serial number is stored
with the system
To assign a serial number , select Security >System
IDs in the Computer Setup (F10) Utility.
ERROR: An unsupported
processor is installed. System
halted
Unsupported processor detected. Replace the processor.
ERROR: A processor requiring
too much power is installed.
System halted
Unsupported processor detected. Replace the processor.
ERROR: Mixing processors
with different power
requirements. This is not
supported. System halted.
Mixed type processors detected. Replace the processors with matched processors.
Invalid electronic serial
number
Incorrect serial number registered in
the system.
Use the Computer Setup (F10) Utility to reset the serial
number.
Mixing processors with
different power requirements.
This is not supported. System
halted.
Mixed type processors detected. Replace the processors with matched processors.
Mixing Two Different
Processor Types MP and DP!!!
Mixed type processors detected. Replace the processors with matched processors.
Network Server Mode Active
and No Keyboard Attached
Keyboard not detected. Verify that a functioning keyboard is attached to the
workstation.
Processor initialization fails!!! Processor defective. Replace the processor.
The installed CPUs have
different voltage requirements.
This is not supported. System
halted.
Mixed type processors detected. Replace processors with matched processors.
Two processors do not have
the same frequency operating
ranges!!!
Mixed type processors detected. Replace processors with matched processors.
ENWW
Diagnostic codes and errors
255

HP Z800 Specifications

General

Processor cache	8 MB
Processor model	E5560
Processor frequency	2.8 GHz
Processor cache type	L2
Processor manufacturer	Intel
Processor front side bus	1333 MHz
Number of processors installed	2
Audio system	Integrated High Definition Realtek ALC262 Audio, optional Creative X-Fi Titanium PCIe Audio Card, optional HP Thin USB Powered Speakers
Product type	Workstation
Motherboard chipset	Intel® 5520
ECC	Yes
Maximum internal memory	192 GB
HDD speed	15000 RPM
HDD capacity	446 GB
HDD interface	Serial Attached SCSI (SAS)
Optical drive type	DVD Super Multi
Card reader integrated	No
I/O ports	Front: 3 USB 2.0, 1 IEEE 1394a, 1 microphone in, 1 headphone out; Rear: 6 USB 2.0, 1 IEEE 1394a, 1 audio in, 1 audio out, 1 microphone in, 2 PS/2, 2 RJ-45 to integrated Gigabit LAN, 1 serial; Internal: 3 USB 2.0
Headphone outputs	1
USB 2.0 ports quantity	9
Parallel ports quantity	0
Power supply	1110 W
Power consumption (typical)	240 W
Non-operating altitude	9100 m
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	8 - 90 %
Operating relative humidity (H-H)	8 - 85 %
Display	HP LP1965 19-inch LCD Monitor, HP LP2065 20-inch LCD Monitor, HP LP2275w 22-inch Widescreen LCD Monitor, HP LP2475w 24-inch Widescreen LCD Monitor, HP DreamColor LP2480zx Professional Display (24-inch widescreen), HP LP3065 30-inch Widescreen LCD Monitor (all sold separately)
Drive bays	3 external 5.25\
Graphics card	-
Keyboard type	HP PS/2 Standard Keyboard
Expansion slots	1 PCI, 1 PCI Express Gen1 (x8 mechanically, x4 electrically), 1 PCI Express Gen2 (x8 mechanically, x4 electrically), 2 PCI Express Gen2 (x16 mechanically, x8 electrically), 2 PCI Express Gen2 x16
Pointing device	HP USB Laser Scroll Mouse
Power requirements	1110 watts wide-ranging, active Power Factor Correction, direct connection Power Supplies
Storage drive type	300 GB 15000 rpm SAS 146 GB 15000 rpm SAS SAS 146 GB + 300 GB
HDD controller type	SATA (10000 rpm) SATA (7200 rpm) SAS (15000 rpm)
Video card features	No integrated Graphic Card
Maximum HDD capacity	450 GB
Storage drive controller	Integrated 6 channel SATA 3 Gb/s controller with RAID (0, 1, 5 or 10) capability, integrated 8 channel SAS controller with RAID (0, 1 or 10) capability, optional LSI 8888 ELP 8-port SAS HW with RAID (0, 1, 5 or 10) capability
Minimum storage drive space	146 GB
Operating system installed	Windows Vista Business
Compatible operating systems	HP Installer Kit for Linux
Chassis type	Mini Tower
Country of origin	China

Weight and Dimensions

Depth	526.5 mm
Width	203.5 mm
Height	445.1 mm
Weight	19500 g
