Secondary slot
To replace the component, reverse the removal procedure.
Removing and replacing an expansion boardRemoving and replacing an expansion board
WARNING: WARNING: To reduce the risk of personal injury from hot surfaces, allow the drives and the internal system components
to cool before touching them.
CAUTION: CAUTION: To prevent damage to electrical components, take the appropriate anti-static precautions before beginning
any installation, removal, or replacement procedure. Improper grounding can cause electrostatic discharge.
CAUTION:CAUTION:
To prevent improper cooling and thermal damage, do not operate the server unless all PCIe slots have either an
expansion slot cover or an expansion card installed.
Use these instructions to remove and replace expansion boards including type -p storage controllers, PCIe accelerators, and network
adapters into the server. For more information on installing controllers, SAS expanders, or GPU cards, see the related section.
PrerequisitesPrerequisites
Before you perform this procedure, make sure that you have the following items:
