4 X8 / X16 slot (primary)
5 Type -a storage controller slot
6 System maintenance switch
7 OCP NIC 3.0 x16 upgrade connector
8 SATA port 1
9 SATA port 2
10 Front panel connector
11 NVMe Slimline 2A
12 NVMe Slimline 1A
13 NVMe Slimline 2B
14 Fan cage signal connector
15 NVMe Slimline 1B
16 Drive cage 3 signal connector
17 Chassis intrusion detection switch connector
18 System battery
19 Fan cage power connector
20 Energy pack connector
21 Drive cage 2 power connector
22 GPU power connector
23 Drive cage 3 power connector
24 Drive cage 1 power connector
25 Secondary PCIe4 riser connector
26 Tertiary PCIe4 riser connector
ItemItem DescriptionDescription
This description may be different from the label on the server.
DIMM slot locationsDIMM slot locations
DIMM slots are numbered sequentially (1 through 12) for each processor. The supported AMP modes use the letter assignments for
population guidelines.
