3. Remove the drive.
To replace the component, reverse the removal procedure.
Removing and replacing a fanRemoving and replacing a fan
Removing and replacing a fan from rear of Removing and replacing a fan from rear of drive cage 2drive cage 2
ProcedureProcedure
1. Extend the server from the rack .
2. Open the access panel to access drive cage 3 to access the fans behind drive cage 2.
3. Remove the fan.
To replace the component, reverse the removal procedure.
Drive cage optionsDrive cage options
